GPD Win 4 2024 Handheld PC Gaming Console (Black) | 6" FHD (1920x1080) | AMD Ryzen 7 8840U | 32GB RAM | 2TB SSD | AMD Radeon 780M | Windows 11 | GPD Win 4 Protective Case
GPD Win 4 2024 Handheld PC Gaming Console (Black) | 6" FHD (1920x1080) | AMD Ryzen 7 8840U | 32GB RAM | 2TB SSD | AMD Radeon 780M | Windows 11 | GPD Win 4 Protective Case
- Screen: 6 inches, 1920 × 1080
- CPU: AMD Ryzen 8840U
- GPU: AMD Radeon 780M
- DDR: 32GB LPDDR5x
- Storage: 2TB PCIe Gen4 M.2 NVMe SSD
- Wireless Network: Wi-Fi 6, 4G LTE (Optional)
- Bluetooth: 5.2
- USB4: × 1, 40Gbps
- USB Type-C: × 1, 3.2 Gen2
- Oculink (SFF-8612): 1, 63Gbps
- microSD Slot: × 1, UHS-Ⅰ A2, U3, V30
- Battery: 45.62Wh
SPECIFICATION
| Basic Information | |
| Product Positioning | Handheld Game Console |
| Operating System | Pre-installed with Windows 11 Home 64bit, with the option to install either Steam OS or GPD OS |
| Display | |
| Touch Panel | Supports |
| Screen Type | Corning Gorilla Glass 5，H-IPS Technology |
| Screen Size | 6 Inches, Native Landscape Mode, DC Dimming |
| Aspect Ratio | 16:09 |
| Screen Resolution | 1920 × 1080, 1280 × 720, Image resolution: 40Hz & 60Hz |
| Pixels Per Inch | 368 PPI |
| CPU | |
| Product model | AMD Ryzen 7 8840U |
| Architecture | Zen 4（Hawk Point） |
| # of CPU Cores / # of Threads | 8C / 16T |
| Base Clock | 3.3 GHz |
| Max. Boost Clock | 5.1 GHz |
| AI Performance | 16 TOPS |
| Total Processor Performance | 38 TOPS |
| Total Cache | 24.5 MB |
| Process Size | 4nm |
| TDP | 15W-30W |
| GPU | |
| Processor Graphics | AMD Radeon 780M |
| Architecture | RDNA 3.0 |
| Graphics Frequency | 2700 MHz |
| Compute Units | 12CU |
| Shading Units | 768 |
| Floating-point Performance | 17.82 TFlops (FP16) |
| 8.92 TFlops (FP32) | |
| 556.8 GFlops (FP64) | |
| Pixel Rate | 92.80 GPixel/s |
| Texture Rate | 139.2 GTexel/s |
| Video Memory | The Default Shared Memory Is 3GB, With A Maximum Allocation Of 16GB, Which Requires Manual Adjustment In The BIOS |
| HDMI | 7680 x 4320 @60Hz |
| DP | 7680 x 4320 @60Hz |
| DirectX | DX12 Ultimate |
| OpenGL | 4.6 |
| Storage | |
| Memory | 32GB |
| Memory Types | LPDDR5x 7500 MT/s |
| Memory Channel | Quad 32-bit Channels |
| Hard Disk Type | M.2 SSD |
| Hard Disk Interface | Socket 3 |
| Hard Disk Specifications | M.2 NVMe 2280 × 1 |
| Standard Capacity | 2TB M.2 NVMe 2280 SSD |
| Bus Specification | PCIe 4.0 × 4 |
| Transfer Protocol | NVMe 1.3 / 1.4 |
| Multimedia Support | |
| Audio System | Built-in Sound Chip + Intelligent Amplifier That Features High Energy Efficiency, High PSRR and Low Noise |
| Loudspeakers | Built-in Dual Speakers |
| Microphone | Built-in Microphone |
| Network Communications | |
| 4G LTE Module | Back-mount Module, Selectable |
| Type of SIM Card: Nano-SIM, Single | |
| 4G Network：TD-LTE，FDD-LTE | |
| 3G Network：WCDMA/TD-SCDMA/CDMA | |
| 2G Network：GSM | |
| Frequency Band： | |
| LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28 | |
| LTE-TDD: B38/B39/B40/B41 | |
| UMTS: B1/B2/B4/B5/B6/B8/B9 | |
| GSM: B2/B3/B5/B8 | |
| Wi-Fi | IEEE 802.11 a/b/g/n/ac/ax, Support 2.4G/5G Dual Frequency Band, Dual Channel Maximum Transmission Rate 2402Mbps |
| Bluetooth | 5.2 |
| I/O Interface | |
| Video / Data / Charging | USB4, 40Gbps (Full Speed) × 1 |
| USB 3.2 Gen 2 Type-C Full-featured, 10Gbps × 1 | |
| USB 3.2 Gen 2 Type-C Charging Only (Provided By The Dock) × 1 | |
| Oculink (SFF-8612) female port with a bandwidth of 63Gbps and a throughput of up to 7.877GB/s × 1 | |
| USB 3.2 Gen 2 Type-A, 10Gbps (Provided By The Dock) × 3 | |
| HDMI 2.0 (Provided By The Dock) × 1 | |
| microSDXC Slot | Bus interface: UHS-I |
| Speed Class: Class 10 | |
| Ultra High Speed: U3 | |
| Video Speed Class: V30 | |
| Application Performance Class: A2 | |
| Read/Write: 160MB/s, 90MB/s | |
| Maximum Capacity: 2TB | |
| Ethernet Interface | RJ45 (Provided By The Dock) × 1 |
| Audio Port | 3.5mm Headphone/Microphone Combo Interface, Compatible With Apple Headphones (US Specification) × 1 |
| BIOS Reset Port | Supports |
| I/O Device | |
| Keyboard | QWERTY Full Keyboard Design, Scissor-Switch Keys, White Backlight, And Combination Keys For On/Off Function |
| Mouse | Mouse 1: Right Joystick Simulates Mouse, Requires Switching Between "Gamepad/Mouse" Mode |
| Mouse 2: Optical Finger Mouse With Support For Click Confirmation Via Pressure | |
| Fingerprint Recognition | Yes |
| Joystick | ALPS OEM Dual 3D Joysticks With Native Support For L3/R3 Via Downward Press |
| D-Pad | Siamese Cross Key |
| Game Function Buttons | ABXY、△○×□ Double Character Print, Select, Start, Xbox Controller Home |
| Game Accessories Buttons | L1/R1 Feature Rainbow Lighting Design, While L2/R2 Are Linear Analog Buttons |
| Handle Vibration | Dual Vibration Motors, Software Controlled, Capable Of: Turning Off, Weak Vibration, Strong Vibration |
| Dorsal Key | Two Back Buttons, Mappable And Programmable |
| Other Keys | Volume +/- Buttons, Power Button, Gamepad/Mouse Mode Switch |
| Sensor | 6-axis Design: 3-axis G-sensor, 3-axis Gyro |
| Speaker | 2 Pcs |
| Indicator Lamp | Charging Indicator, Running Indicator |
| Battery | |
| Battery Type | Li-polymer |
| Battery Capacity | 45.62Wh |
| Battery Life | Up to 2 Hours Of Heavy Use, Up to 3-6 Hours Of Moderate Use, Up to 10 Hours Of Light Use, Depending On The Specific Environment Of Use |
| Appearance | |
| Net Weight | 598g |
| Length | 220×92×28mm |
| Shell Material | LG-DOW 121H Aviation ABS, UL94-V0, Magnesium Alloy |
| Shell Color | Black |
| Thermal Design | Active Thermal Dissipation, Large Fan, Double Thick-walled Heat Pipes |
