Seasonic Syncro Q704 Aluminum Mid Tower PC Case + DGC-750 750W 80+ Gold Power Supply (SSR-750FA2)
Seasonic Syncro Q704 Aluminum Mid Tower PC Case + DGC-750 750W 80+ Gold Power Supply (SSR-750FA2)
SYNCRO PSU
The SYNCRO CONNECT boasts a novel aesthetic and functional upgrade to the usual characteristics of a PC power supply. It is comprised of two linked products, featuring a visually pleasing CONNECT module and a Seasonic SYNCRO power supply. The CONNECT module doesn’t compromise on any of the typically top-level features of high quality Seasonic power supplies, as it naturally comes with fully modular cables for custom installation, as well-known Seasonic energy-efficient S3FC technology for optimized cooling and quiet operation. The design idea is a first step towards a plethora of future possibilities on the way to an entirely reimagined PC interior.
In North America, the SYNCRO power supply plus CONNECT Module set is sold under a separate listing from the SYNCRO Q704 PC chassis.
In the EU and the UK, the SYNCRO Power Supply plus CONNECT Module is sold together with the SYNCRO Q704 case as a bundle.
| Technical Specifications | ||
|---|---|---|
| 80PLUS® | Gold | |
| Cybenetics Efficiency Level | TBA | |
| Cybenetics Noise Level | TBA | |
| Form Factor | ATX/EPS | |
| Dimensions | 140 × 150 × 86 mm | |
| Fan Information | Fan Size | 135 mm |
| Fan Control | Premium Hybrid Fan Control | |
| Fan Bearing | Fluid Dynamic Bearing | |
| Life Expectancy | 50,000 hours at 40 °C, 15 % - 65 % RH | |
| Cable Information | Modularity | Fully Modular |
| Electrical Features | Operating Temperature | 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C linearly) |
| MTBF @ 25 °C, excl. fan | 150,000 hours | |
| AC Input | Full Range | |
| Protection | OPP, OVP, UVP, OCP, OTP, SCP | |
| Safety and Environmental | Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
| Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH | |
| Power Output | ||||||
|---|---|---|---|---|---|---|
| AC Input | 100 V - 240 V | |||||
| 10 - 5 A | ||||||
| 50 Hz - 60 Hz | ||||||
| DC Output | Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
| Maximum Power | 20 A | 20 A | 62 A | 0.3 A | 3 A | |
| 100 W | 744 W | 3.6 W | 15 W | |||
| Total continuous power | 750 W | |||||
