Samsung 990 Evo Plus PCIe 4.0 x4 / 5.0 x2 NVMe M.2 SSD (1TB, 2TB, 4TB)
990 EVO Plus NVMe M.2 SSD
SPECIFICATION
| General Feature | |
| Application | Client PCs |
| Form Factor | M.2 (2280) |
| Dimension (Pack: WxHxD) | Max 80.15 x Max 22.15 x Max 2.38 mm |
| Rated Capacity | 4,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
| Interface | PCIe® 4.0 x4 / 5.0 x2 NVMe™ 2.0 |
| Dimension (Pack: WxHxD) | Max 80.15 x Max 22.15 x Max 2.38 mm |
| Storage Memory | Samsung V-NAND TLC |
| Cache Memory | HMB(Host Memory Buffer) |
| Controller | Samsung in-house Controller |
| Special Feature | |
| TRIM Support | Supported |
| GC (Garbage Collection) | Auto Garbage Collection Algorithm |
| WWN Support | Not supported |
| S.M.A.R.T Support | Supported |
| Encryption Support | AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
| Device Sleep Mode Support | Yes |
| Performance | |
| Sequential Read | Up to 7,250 MB/s * |
| Random Read (4KB, QD32) | Up to 1,050,000 IOPS * Performance may vary based on system hardware & configuration |
| Sequential Write | Up to 6,300 MB/s * |
| Random Write (4KB, QD32) | Up to 1,400,000 IOPS * Performance may vary based on system hardware & configuration |
| Environment | |
| Average Power Consumption (system level) | Average: Read 5.5 W / Write 4.8 W* Actual power consumption may vary depending on system hardware & configuration |
| Power Consumption (Device Sleep) | Typical 5 mW * Actual power consumption may vary depending on system hardware & configuration |
| Reliability (MTBF) | 1.5 Million Hours Reliability (MTBF) |
| Shock | 1,500 G & 0.5 ms (Half sine) |
| S.M.A.R.T Support | Supported |
| Encryption Support | AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
| Device Sleep Mode Support | Yes |
Select Choose Storage
From $49.39
Original: $164.64
-70%Samsung 990 Evo Plus PCIe 4.0 x4 / 5.0 x2 NVMe M.2 SSD (1TB, 2TB, 4TB)—
$164.64
$49.39
Description
990 EVO Plus NVMe M.2 SSD
SPECIFICATION
| General Feature | |
| Application | Client PCs |
| Form Factor | M.2 (2280) |
| Dimension (Pack: WxHxD) | Max 80.15 x Max 22.15 x Max 2.38 mm |
| Rated Capacity | 4,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
| Interface | PCIe® 4.0 x4 / 5.0 x2 NVMe™ 2.0 |
| Dimension (Pack: WxHxD) | Max 80.15 x Max 22.15 x Max 2.38 mm |
| Storage Memory | Samsung V-NAND TLC |
| Cache Memory | HMB(Host Memory Buffer) |
| Controller | Samsung in-house Controller |
| Special Feature | |
| TRIM Support | Supported |
| GC (Garbage Collection) | Auto Garbage Collection Algorithm |
| WWN Support | Not supported |
| S.M.A.R.T Support | Supported |
| Encryption Support | AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
| Device Sleep Mode Support | Yes |
| Performance | |
| Sequential Read | Up to 7,250 MB/s * |
| Random Read (4KB, QD32) | Up to 1,050,000 IOPS * Performance may vary based on system hardware & configuration |
| Sequential Write | Up to 6,300 MB/s * |
| Random Write (4KB, QD32) | Up to 1,400,000 IOPS * Performance may vary based on system hardware & configuration |
| Environment | |
| Average Power Consumption (system level) | Average: Read 5.5 W / Write 4.8 W* Actual power consumption may vary depending on system hardware & configuration |
| Power Consumption (Device Sleep) | Typical 5 mW * Actual power consumption may vary depending on system hardware & configuration |
| Reliability (MTBF) | 1.5 Million Hours Reliability (MTBF) |
| Shock | 1,500 G & 0.5 ms (Half sine) |
| S.M.A.R.T Support | Supported |
| Encryption Support | AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
| Device Sleep Mode Support | Yes |
