Phanteks Eclipse P200A DRGB Tempered Glass Mini-ITX Digital RGB Lightning Case (Satin Black) (PH-EC200ATG-DBK01)

Phanteks Eclipse P200A DRGB Tempered Glass Mini-ITX Digital RGB Lightning Case (Satin Black) (PH-EC200ATG-DBK01)

Features

  • Ultra-fine Performance Mesh front and side panels for the highest cooling performance while showcasing your system through the Tempered Glass Window
  • Spacious open interior supports ATX power supplies, triple slot graphics cards, vertical GPU mounting support (with PH-CBRS-FL15) and up to 240/280mm front and 240mm side radiators
  • Front I/O with 10Gbps USB-C gen 2
  • Integrated Digital-RGB controller that can sync with compatible motherboards and Phanteks D-RGB products to create stunning lighting effects and comes with 2x DRGB Phanteks fans
  • Storage support for 2x 2.5” SSD and up to 4 HDD (with PH-HDDKT_03)
Model Name Eclipse P200A D-RGB
Model PH-EC200ATG DBK_01
UPC Code 886523302186
Case Dimension (W x H x D) 205 × 365 × 400 mm / 8.1 × 14.4 × 15.7 in
Form Factor Mini Tower
Materials Steel Chassis, Tempered Glass
Motherboard Support Mini-ITX, mini-ITX
Front I/O USB-C GEN 2 (10Gbps)
2x USB 3.0
Microphone/Headphone
LED Mode Button
LED Color Button
Power Button
Power Switch
Internal Connectors D-RGB Expansion
D-RGB Third Party
D-RGB-MB Adapter
HD-audio
USB 3.0
USB 3.2 GEN2 Type-E
Side Window Tempered Glass Window
Vertical GPU Yes, 3-slots (Riser Cable sold separately)
Internal 3.5" Bay 4 (Stackable 3.5" Bracket sold separately/not included)
Internal 2.5" Bay 4 (4x included)
Total Fan Mounts 7x120 mm / 2x140 mm + 5x120 mm
Front Fan 2x120 mm / 2x140 mm (2x120 mm D-RGB PWM included)
Side Fan 2x120 mm
Rear Fan 1x120 mm
Bottom Fan 2x120 mm
Dust Filters Bottom
Front Radiator Up to 240 mm / Up to 280 mm
Side Radiator Up to 240 mm
Rear Radiator 120 mm
Front Radiator Clearance 140 × 325 mm
Side Radiator Clearance 120 × 279 mm
GPU Length 355 mm / 13.98 in
GPU Thickness 3-slot, 65 mm
CPU Cooler Height 165 mm / 6.5 in
CPU Cooler Height with Vertical GPU 72 mm or 92 mm depending on Vertical PCI slot position
PSU Length 205 mm (190 mm recommended)
Package Dimension 415 × 285 × 485 mm / 16.3 × 11.2 × 19.1 in
Net Weight 5.5 kg / 12 lbs
Gross Weight 6.6 kg / 15 lbs
Package Contents 1x Eclipse P200A Case
2x 25° 550 Covers
Bracket (for 2x 2.5" SSD)
2x SK 120mm PWM D-RGB fans
6Zip
1x Vertical GPU mount
1x Accessory Bag with necessary screws and standoffs
$18.41

Original: $61.35

-70%
Phanteks Eclipse P200A DRGB Tempered Glass Mini-ITX Digital RGB Lightning Case (Satin Black) (PH-EC200ATG-DBK01)—

$61.35

$18.41
Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6

Description

Features

  • Ultra-fine Performance Mesh front and side panels for the highest cooling performance while showcasing your system through the Tempered Glass Window
  • Spacious open interior supports ATX power supplies, triple slot graphics cards, vertical GPU mounting support (with PH-CBRS-FL15) and up to 240/280mm front and 240mm side radiators
  • Front I/O with 10Gbps USB-C gen 2
  • Integrated Digital-RGB controller that can sync with compatible motherboards and Phanteks D-RGB products to create stunning lighting effects and comes with 2x DRGB Phanteks fans
  • Storage support for 2x 2.5” SSD and up to 4 HDD (with PH-HDDKT_03)
Model Name Eclipse P200A D-RGB
Model PH-EC200ATG DBK_01
UPC Code 886523302186
Case Dimension (W x H x D) 205 × 365 × 400 mm / 8.1 × 14.4 × 15.7 in
Form Factor Mini Tower
Materials Steel Chassis, Tempered Glass
Motherboard Support Mini-ITX, mini-ITX
Front I/O USB-C GEN 2 (10Gbps)
2x USB 3.0
Microphone/Headphone
LED Mode Button
LED Color Button
Power Button
Power Switch
Internal Connectors D-RGB Expansion
D-RGB Third Party
D-RGB-MB Adapter
HD-audio
USB 3.0
USB 3.2 GEN2 Type-E
Side Window Tempered Glass Window
Vertical GPU Yes, 3-slots (Riser Cable sold separately)
Internal 3.5" Bay 4 (Stackable 3.5" Bracket sold separately/not included)
Internal 2.5" Bay 4 (4x included)
Total Fan Mounts 7x120 mm / 2x140 mm + 5x120 mm
Front Fan 2x120 mm / 2x140 mm (2x120 mm D-RGB PWM included)
Side Fan 2x120 mm
Rear Fan 1x120 mm
Bottom Fan 2x120 mm
Dust Filters Bottom
Front Radiator Up to 240 mm / Up to 280 mm
Side Radiator Up to 240 mm
Rear Radiator 120 mm
Front Radiator Clearance 140 × 325 mm
Side Radiator Clearance 120 × 279 mm
GPU Length 355 mm / 13.98 in
GPU Thickness 3-slot, 65 mm
CPU Cooler Height 165 mm / 6.5 in
CPU Cooler Height with Vertical GPU 72 mm or 92 mm depending on Vertical PCI slot position
PSU Length 205 mm (190 mm recommended)
Package Dimension 415 × 285 × 485 mm / 16.3 × 11.2 × 19.1 in
Net Weight 5.5 kg / 12 lbs
Gross Weight 6.6 kg / 15 lbs
Package Contents 1x Eclipse P200A Case
2x 25° 550 Covers
Bracket (for 2x 2.5" SSD)
2x SK 120mm PWM D-RGB fans
6Zip
1x Vertical GPU mount
1x Accessory Bag with necessary screws and standoffs
