INNO3D GeForce RTX 5070 Twin X2 12GB GDDR7 Graphics Card (N50702-12D7-195064N)

GPU

Chipset Manufacturer	NVIDIA
Chipset Model Name	GeForce RTX
Chipset Model Number	5070
Chipset Additional Information	Twin X2
Base Chip Clock	2325 MHz
Boost Chip Clock	2512 MHz
Graphics Core	CUDA
Number of Cores	6144

Memory

Memory Size	12288 MB
Memory Clock	28 Gbps
Memory Type	GDDR7
Memory Width	192 bit
Memory Bandwidth	672 GB/s

Interfaces/Ports

Video Card Bus Type	PCI Express
Video Card Bus Version	5.0 x16
HDMI Port	1 x HDMI 2.1b
DisplayPort	3 x DisplayPort 2.1b

Resolution

Multiple Monitor Support (Max)	Yes (4)
Maximum Resolution	7680 x 4320

System Requirements

System Requirements

1 x PCI Express 5.0 x16 slot

Electrical

Power Connector	1 x 12V-2x6 or 2 x 8-pin PCIe
Power Consumption	250 W
Recomended Power Supply	650 W

Physical

Form Factor	Graphics Card
In The Box	Graphics Card 1 x 12V-2x6 to 2 x 8-pin PCIe adapter
Width	41 mm (2.05 slot)
Depth	250 mm
Height	116 mm

Key Features

Interface Type	PCI Express 5.0 x16
Config Gaming x8 (CB/CCL)	No
Graphics Memory Type	GDDR7
Main Colour	Black
VGA Connection	No
DVI Connection	No
HDMI Connection	Yes
Graphics Usability	Gaming
DisplayPort Connection	Yes
Direct X Support	Direct X 12
Cooler Type	Dynamic Fan Inc. 0dB Mode
Low Profile	No
NVIDIA GeForce	RTX 5070
PCIe Pin Type	12+4-Pin (16-Pin)
Cooling Technology	Dynamic Fan Inc. 0dB Mode
VR Ready	NVIDIA
GPU Length	250 mm
Card Width	2
Power Requirement (auto)	250 W
GPU Power (TDP)	250 W
Graphics card count	1
PCI Express Power Pins (female)	16
PCIe Physical Slot required	16
12VHPWR 16-pin Connector	Yes
AI Ready	Yes
12V-2x6 Rating	300W

Graphics

Graphics Chipset

GeForce RTX 5070

Graphics Device

G-Sync

Yes
