Fractal Design Meshify 2 Compact Computer Case (Black Solid, Black TG Light Tint) (FD-C-MES2C-01, FD-C-MES2C-03)

Fractal Design Meshify 2 Compact Computer Case (Black Solid, Black TG Light Tint) (FD-C-MES2C-01, FD-C-MES2C-03)

Meshify 2 Compact

Meshify 2 Compact is a high-performing case with a bold, stealth-inspired aesthetic. Its striking exterior features bolt-free, flush tempered glass, a fully removable top panel granting excellent interior access, and a front USB 3.2 Type-C port.

  • Iconic angular mesh front provides filtered airflow with a bold, stealth-inspired aesthetic
  • Room for GPUs up to 360 mm with a 240 mm radiator in the top, or up to 360/280 mm front radiators with GPUs under 305 mm
  • Versatile and space-efficient ATX form-factor design offers the performance and capacity of much larger cases

SPECIFICATION

3.5"/2.5" Universal drive mounts 2 (included)
Dedicated 2.5" drive mounts 4 (2 included)
Expansion slots 7
Front interface 1x USB 3.2 Gen 2x2 Type-C (20 Gbps), 2x USB 3.0, Audio I/O, Power button, Reset button
Total fan mounts 7x 120 or 4x 140 mm and 2x 120 mm
Front fan 3x 120 or 2x 140 mm, (2x Dynamic X2 GP-14 included)
Top fan 2x 120/140 mm
Rear fan 1x 120 mm, (1x Dynamic X2 GP-12 included)
Bottom fan 1x 120 mm (requires removal of HDD cage)
Dust filters Top, front and bottom
Fixed velcro straps Yes
Cable routing grommets Yes
Captive thumbscrews HDD, SSD and PSU brackets
Left side panel Steel
Right side panel Steel
Motherboard compatibility ATX / mATX / Mini-ITX
Power supply type ATX
PSU max length 200 mm (165 mm with HDD cage and front fan)
GPU max length 341 mm (360 mm without front fan)
CPU cooler max height 169 mm
Front radiator Up to 360/280 mm
Top radiator Up to 240 mm
Rear radiator 120 mm
Bottom radiator 120 mm (requires removal of HDD cage)
Cable routing space 17-28 mm
Radiator Support – Additional Details Maximum radiator width: 145mm for front mounting. Maximum motherboard component height for top mounted radiator: 40 mm. For more details, consult the manual.
Case dimensions (LxWxH) 424 x 210 x 475 mm
Case dimensions w/o feet/protrusions/screws 412 x 210 x 455 mm
Package dimensions (LxWxH) 542 x 320 x 554 mm
Select Choose your color:
From $35.27

Original: $117.58

-70%
Fractal Design Meshify 2 Compact Computer Case (Black Solid, Black TG Light Tint) (FD-C-MES2C-01, FD-C-MES2C-03)—

$117.58

$35.27
Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6
Product image 7
Product image 8
Product image 9
Product image 10
Product image 11
Product image 12
Product image 13
Product image 14
Product image 15
Product image 16
Product image 17
Product image 18
Product image 19
Product image 20
Product image 21
Product image 22
Product image 23
Product image 24
Product image 25
Product image 26
Product image 27
Product image 28
Product image 29
Product image 30
Product image 31
Product image 32
Product image 33
Product image 34

Description

Meshify 2 Compact

Meshify 2 Compact is a high-performing case with a bold, stealth-inspired aesthetic. Its striking exterior features bolt-free, flush tempered glass, a fully removable top panel granting excellent interior access, and a front USB 3.2 Type-C port.

  • Iconic angular mesh front provides filtered airflow with a bold, stealth-inspired aesthetic
  • Room for GPUs up to 360 mm with a 240 mm radiator in the top, or up to 360/280 mm front radiators with GPUs under 305 mm
  • Versatile and space-efficient ATX form-factor design offers the performance and capacity of much larger cases

SPECIFICATION

3.5"/2.5" Universal drive mounts 2 (included)
Dedicated 2.5" drive mounts 4 (2 included)
Expansion slots 7
Front interface 1x USB 3.2 Gen 2x2 Type-C (20 Gbps), 2x USB 3.0, Audio I/O, Power button, Reset button
Total fan mounts 7x 120 or 4x 140 mm and 2x 120 mm
Front fan 3x 120 or 2x 140 mm, (2x Dynamic X2 GP-14 included)
Top fan 2x 120/140 mm
Rear fan 1x 120 mm, (1x Dynamic X2 GP-12 included)
Bottom fan 1x 120 mm (requires removal of HDD cage)
Dust filters Top, front and bottom
Fixed velcro straps Yes
Cable routing grommets Yes
Captive thumbscrews HDD, SSD and PSU brackets
Left side panel Steel
Right side panel Steel
Motherboard compatibility ATX / mATX / Mini-ITX
Power supply type ATX
PSU max length 200 mm (165 mm with HDD cage and front fan)
GPU max length 341 mm (360 mm without front fan)
CPU cooler max height 169 mm
Front radiator Up to 360/280 mm
Top radiator Up to 240 mm
Rear radiator 120 mm
Bottom radiator 120 mm (requires removal of HDD cage)
Cable routing space 17-28 mm
Radiator Support – Additional Details Maximum radiator width: 145mm for front mounting. Maximum motherboard component height for top mounted radiator: 40 mm. For more details, consult the manual.
Case dimensions (LxWxH) 424 x 210 x 475 mm
Case dimensions w/o feet/protrusions/screws 412 x 210 x 455 mm
Package dimensions (LxWxH) 542 x 320 x 554 mm
