Cooler Master MWE 650 Bronze V2 230V 650W 80+ Non Modular Power Supply
MWE 650 BRONZE - V2 230V
80 PLUS BRONZE CERTIFIED 230V POWER SUPPLY UNIT
DC-to-DC + LLC Circuit Design
High Temperature Resistance
Peak Power Tolerance
80 PLUS Bronze 230V EU Certified
Durable, Reliable, and Safe
Specifications:
|
Model
|
MPE-6501-ACABW-B |
|
ATX Version
|
ATX 12V V2.52 |
|
PFC
|
Active PFC |
|
Input Voltage
|
200-240Vac |
|
Input Current
|
10-5A |
|
Input Frequency
|
50-60Hz |
|
Dimensions (L x W x H)
|
140 x 150 x 86 mm |
|
Fan Size
|
120mm |
|
Fan Bearing
|
HDB |
|
Fan Speed
|
2400 RPM |
|
Noise Level @ 20%
|
16.54 dBA |
|
Noise Level @ 50%
|
26.5 dBA |
|
Noise Level @ 100%
|
42.5 dBA |
|
Efficiency
|
88% Typically |
|
80 PLUS Rating
|
80 PLUS Bronze EU 230V |
|
ErP 2014 Lot 3
|
Yes |
|
Power Good Signal
|
100 - 500 ms |
|
Hold Up Time
|
>14ms at 100% Full Load@230Vac |
|
MTBF
|
>100,000 Hours |
|
Protections
|
OVP, OPP, SCP, UVP, OTP |
|
Regulatory
|
CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
|
ATX 24 Pin Connectors
|
1 |
|
EPS 4+4 Pin Connectors
|
1 |
|
EPS 8 Pin Connector
|
1 |
|
SATA Connectors
|
6 |
|
Peripheral 4 Pin Connectors
|
3 |
|
PCI-e 6+2 Pin Connectors
|
4 |
|
Series
|
MWE Bronze Series |
|
80 Plus
|
Bronze |
|
Modular
|
Non Modular |
|
Category
|
500 to 750W |
$16.39
Original: $54.63
-70%Cooler Master MWE 650 Bronze V2 230V 650W 80+ Non Modular Power Supply—
$54.63
$16.39
Description
MWE 650 BRONZE - V2 230V
80 PLUS BRONZE CERTIFIED 230V POWER SUPPLY UNIT
DC-to-DC + LLC Circuit Design
High Temperature Resistance
Peak Power Tolerance
80 PLUS Bronze 230V EU Certified
Durable, Reliable, and Safe
Specifications:
|
Model
|
MPE-6501-ACABW-B |
|
ATX Version
|
ATX 12V V2.52 |
|
PFC
|
Active PFC |
|
Input Voltage
|
200-240Vac |
|
Input Current
|
10-5A |
|
Input Frequency
|
50-60Hz |
|
Dimensions (L x W x H)
|
140 x 150 x 86 mm |
|
Fan Size
|
120mm |
|
Fan Bearing
|
HDB |
|
Fan Speed
|
2400 RPM |
|
Noise Level @ 20%
|
16.54 dBA |
|
Noise Level @ 50%
|
26.5 dBA |
|
Noise Level @ 100%
|
42.5 dBA |
|
Efficiency
|
88% Typically |
|
80 PLUS Rating
|
80 PLUS Bronze EU 230V |
|
ErP 2014 Lot 3
|
Yes |
|
Power Good Signal
|
100 - 500 ms |
|
Hold Up Time
|
>14ms at 100% Full Load@230Vac |
|
MTBF
|
>100,000 Hours |
|
Protections
|
OVP, OPP, SCP, UVP, OTP |
|
Regulatory
|
CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
|
ATX 24 Pin Connectors
|
1 |
|
EPS 4+4 Pin Connectors
|
1 |
|
EPS 8 Pin Connector
|
1 |
|
SATA Connectors
|
6 |
|
Peripheral 4 Pin Connectors
|
3 |
|
PCI-e 6+2 Pin Connectors
|
4 |
|
Series
|
MWE Bronze Series |
|
80 Plus
|
Bronze |
|
Modular
|
Non Modular |
|
Category
|
500 to 750W |
