Be Quiet! System Power 9 700W 80+ Bronze Semi-Modular Power Supply (SM-CM-700W)
SYSTEM POWER 9 CM
700W
Proven reliability and good efficiency
be quiet! System Power 9 CM 700W offers renowned be quiet! reliability and quietness for cost-effective and reliable systems.
- Rock-solid stability with 2 strong 12V-rails
- DC-to-DC technology for tight voltage regulation
- 4 PCIe connectors for powerful GPUs
- Temperature-controlled 120mm fan reduces system noise
- Stand-by drain of less than 0.15 watts
- 80 PLUS® Bronze efficiency (up to 89%)
- Semi-modular, high-quality sleeved and flat cables
- All-in-one cable with S-ATA, HDD and FDD connectors
- Complete suite of top safety features
- Meets latest Intel® C6/C7, ErP and Energy Star 6.1 guidelines
General data
| Model |
System Power 9 CM 700W |
|
Continuous power (W) |
700 |
| Peak power (W) |
- |
| Form factor |
Version 2.51 |
| Form factor EPS 12V
|
Version 2.92 |
| Topology |
DC/DC |
| Digitally controlled |
- |
|
Voltage (Vac) |
200 - 240 |
| Frequency (Hz) |
50 |
| Input current (A) |
6 |
| Power factor at 100% load |
>0.95 |
| Modern standby
|
- |
| Power consumption in standby (W) |
<0.15 |
| Average life time (h / 25°C) |
100,000 |
| Operating temperature up to (°C) |
40 |
|
80 PLUS certification |
Bronze |
|
Efficiency (%) at 230V, 2% load |
- |
|
Efficiency (%) at 230V, 10% load |
84.9 |
|
Efficiency (%) at 230V, 20% load |
88 |
|
Efficiency (%) at 230V, 50% load |
89 |
|
Efficiency (%) at 230V, 100% load |
86 |
| Cybenetics Noise Rating |
- |
| Fan |
High quality fan |
| Fan size (mm) |
120 |
| Bearing technology |
Sleeve |
| Motor technology |
4-pole fan motor |
| Max. fan speed (rpm) |
2100 |
|
dB(A) at 10% load |
9.7 |
|
dB(A) at 20% load |
9.7 |
|
dB(A) at 50% load |
14.1 |
|
dB(A) at 100% load |
31.7 |
| Multi-rail operation (12V rails) |
2 |
| 12V single rail operation |
- |
| Overclocking key |
- |
| +3.3V (A) |
24 |
| +5V (A) |
15 |
| +12V1 (A) |
33 |
| +12V2 (A) |
25 |
| +12V3 (A) |
- |
| +12V4 (A) |
- |
| +12V5 (A) |
- |
| +12V6 (A) |
- |
| -12V (A) |
0.3 |
| +5Vsb (A) |
3 |
| Max. combined power 12V (W) |
672 |
| Max. combined power 12VHPWR (W) |
- |
| Max. combined power 3.3V + 5V (W) |
130 |
|
Hold-up time at 100% load (ms) |
17.0 |
|
Hold-up time at 80% load (ms) |
22.0 |
| Power good signal (ms) |
100 - 150 |
| Modular cables |
- |
| Sleeved cables |
P24, P4+4 |
| Flat cables |
PCIe / drives |
| Maximum cable length (cm) |
103 |
| Cable length to motherboard (cm) |
55 |
| No. of cables |
7 |
|
ATX-Motherboard (20+4-pin) |
1 |
|
P4+4 (CPU) |
1 |
|
P8 (CPU) |
- |
|
P4 (CPU) |
- |
| 12VHPWR cables |
- |
|
PCI-e 6+2-pin (GPU) |
4 |
|
PCI-e 6-pin (GPU) |
- |
| SATA |
10 |
| PATA |
2 |
|
FDD (Floppy) |
1 |
|
OTP (over temperature protection) |
✓ |
|
OCP (over current protection) |
✓ |
|
OPP (over power protection) |
✓ |
|
SCP (short circuit protection) |
✓ |
|
OVP (over Voltage protection) |
✓ |
|
UVP (under Voltage protection) |
✓ |
|
SIP (Surge & Inrush protection) |
✓ |
| BSMI |
- |
| CB |
✓ |
| CCC |
- |
| CE |
✓ |
| cRUus |
- |
| cTUVus |
- |
| CU |
✓ |
| FCC |
- |
| RCM |
✓ |
| TÜV |
✓ |
| UKCA |
- |
| Energy Star |
6.1 |
| ErP |
✓ |
| WEEE |
✓ |
| RoHS |
✓ |
| Triman |
✓ |
| Thumb screws |
- |
| Screws |
✓ |
| Cable ties |
- |
| Velcro cable ties |
- |
| User manual languages |
DE, EN, ES, FR, PL, RU |
| OCK slot bracket with switch / OCK jumper |
- |
|
SFX-to-ATX adapter bracket |
- |
| Dimensions without cable (L x W x H), (mm) |
140 x 150 x 86 |
| Weight (kg) |
1.69 |
| Color |
Black |
