Ayaneo Retro AM01 AMD Ryzen 3 3200U 16GB RAM + 512GB SSD Windows 11 Home Mini PC

Creator in Retro Mini PC

AYANEO's first Mini PC - AM01, a mini PC that blends nostalgia with
modern technology. New design aesthetics, versatile hardware
configuration, full-scene coverage.
Born extraordinary, leading the Mini PC 2.0 era.



SPECIFICATION

CPU	AMD Ryzen™ 3 3200U
Memory	16GB DDR4
SSD	Bare system has no memory or hard drive
	512GB
	1*M.2 2280 PCIe 3.0 slot / support NVMe and SATA SSD
	1 * SATA 3.0 interface / support 2.5" SSD and HDD (bracket required)
Connect	WIFI 5 / BT 4.2 | M.2 2230
Interface Type	1*USB 3.2 Gen1 Type-C (data only)
	3*USB-A 3.2 Gen2
	1*USB-A 2.0
	1*HDMI 2.0
	1*DP 1.4
	1*3.5mm headphone jack
	1*RJ45 Gigabit Ethernet port
	1*DC Power Connector
Heat Dissipation	35W large size high pressure turbo fan
	Four copper tube heat dissipation module Total aluminum fin area 60008.0mm簡"
Power Rating	12V 6A / 7A ( Depending on specific model ）
Size	132 x 132 x 60.5mm (including feet 64.5mm)
Weight	Bare system eidtion: 466g
OS	Windows 11 64 Bit Home Edition / Bare System
